5" three-part house water filter housings offer the versatility to meet all customer filtration needs. It is dedicated for cold water on light commercial and residential applications. This housing is compatible with a broad range of 2 1/2” x 5" type cartridges widely available on the market. Filter housing consists of: a sump, ring and head with brass 1/2", 3/4" and 1” inlet/outlet inserts. Heads are equipped with a pressure relief valve (providing ability to release air bubbles collected during cartridge replacement procedure). The tri-part design ensures maximum leak proof performance and ease of filter cartridge replacement. Series of housings can be mounted individually or connected in a series. It was tested and certified by NSF for structural integrity and material requirements. It is equipped with mounting bracketand wrench.
Specifications:
- High quality
- Hand built and factory tested;
- Domestic and commercial use;
- Three-part design (ideal connection stability);
- Equipped with filter bracket and wrench;
- Easy to connect to cold water inlet;
- Easy to install, no electricity/drain required;
- Housing (sump): poly(ethylene terephtalate) (PET);
- Cap: polypropylene;
- Ring: polypropylene;
- Pressure relief valve: brass;
- O-ring: NBR;
- Thread: 1/2", 3/4" or 1" BSP brass insert;
- Operating Pressure: 6 bar (90 psi);
- Minimum working temperature: 2C (35F);
- Maximum working temperature: 45C (113F);
- Dimensions without bracket (H x OD): 190 mm x 105 mm;
- Dimensions with bracket (H x W x L): 235 mm x 105 mm x 125 mm;
- Cartridge dimensions: 4 7/8" x 2 1/2" (125 mm x 65 mm).
